SC120AT

SC120AT

SmartSens Technology

1.3 MP, 30 to 60 Frames/sec, 1288 x 968 Resolution Image Sensor

1288 (H) x 968 (V)

1.3 MP

1/3.7 英寸

滚动快门

30 to 60 Frames/sec

1.3 MP

3 µm x 3 µm

8083 mV/Lux-s

100 to 120 dB

SmartClarityTM -2

43 dB

8 位, 10 位, 12 位, 14 位, 16 位, 20 位

2.8 V (模拟), 1.2 V (数字), 1.8 V (I/O)

CSP, iBGA, COB, RW

输出格式: YUV 422, CRA: 15 Degrees

MIPI, DVP, LVDS

后视摄像头, 360° 环视摄像头, 盲点检测

41 针 CSP 包装, 72 针 iBGA 包装, COB/RW 包装

5.74 mm x 4.82 mm (CSP), 7.3 mm x 6.65 mm (iBGA), 5.7 mm x 4.78 mm (COB), 5.75 mm x 4.83 mm (RW)

-40 to 105 Degree C
